Project Overview
A fuel-cell vehicle-to-grid model that coordinates the fuel-cell stack, battery buffer and bidirectional grid converter for charging and power export.
The model is structured around fuel-cell power conditioning, battery buffering, bidirectional grid exchange and V2G mode management. It is suitable for scholars who need a clear implementation path, measurable outputs and a page that connects the video demonstration with the underlying engineering method.
System Architecture and Main Components
- Fuel-cell stack and hydrogen subsystem
- DC-DC boost converter
- Battery energy buffer
- Vehicle DC bus
- Bidirectional grid inverter
- V2G power and DC-link controllers
MATLAB / Simulation Methodology
- Configure the fuel-cell polarization and dynamic response.
- Regulate stack power through the unidirectional boost converter.
- Use the battery to support fast transients and SOC constraints.
- Synchronize the bidirectional inverter with the grid.
- Switch between charging, vehicle support and grid-export modes.
Control and Analysis Strategy
The central technical emphasis is fuel-cell power conditioning, battery buffering, bidirectional grid exchange and V2G mode management. Measurements are converted into controller or analysis variables, limits are applied to maintain realistic operation, and disturbances are introduced to evaluate stability, tracking quality, efficiency and transient performance.
The implementation can be extended with parameter optimization, artificial-intelligence control, comparative algorithms, hardware-in-the-loop preparation or publication-style performance indices, depending on the research objective.
Expected Simulation Outputs
- Fuel-cell voltage, current and power
- Battery SOC and power
- DC-link voltage
- Grid current and exported active power
- Charging and V2G operating modes
Video Summary and Simulation Transcript
The video begins with the complete Fuel Cell Vehicle-to-Grid (V2G) System - MATLAB Simulink Explained model and identifies the principal subsystems: Fuel-cell stack and hydrogen subsystem, DC-DC boost converter, Battery energy buffer, Vehicle DC bus.
It then explains the signal flow and demonstrates fuel-cell power conditioning, battery buffering, bidirectional grid exchange and V2G mode management. Reference commands and operating conditions are applied so that the controller, converter or physical model can be observed during steady-state and transient operation.
The final scopes focus on fuel-cell voltage, current and power, battery soc and power, dc-link voltage, grid current and exported active power. These plots support result discussion, controller comparison, report preparation and further PhD or FYP development.
Research Applications and Possible Extensions
- Fuel-cell EV grid services
- Distributed frequency support
- V2G energy-management research
- Hydrogen mobility studies
- Controller or algorithm comparison using identical operating scenarios
- Parameter sensitivity, optimization and publication-style result analysis
Related Simulation Projects
Project Content Note
The page describes a representative project workflow. The exact model, parameters, controller and results may vary according to the selected research paper or university requirement.
